EYECATCHER IN A COMPACT FORMAT

Fire has an archaic power and exerts an immense fascination. It creates warmth, light and atmosphere. The fireplace fire is clearly the focus of Living Fire's modern fireplace systems. Their straight, reduced design underlines the impressive dynamics and power of the flames. Depending on individual wishes and the structural conditions, fireplace systems with different pane variants are available: with a single, wide panoramic pane or as a corner solution with two panes arranged in an L shape. U-shaped models with three viewing panes allow maximum fire visibility from all points in the room. In addition to the impressive, modern appearance, LIVING FIRE fireplace systems impress with their time-saving setup; the devices are delivered ready for installation. They are therefore quick, uncomplicated and clean to assemble.

The innovative Saphir compact system was developed for houses and flats with little space or low heating requirements and impresses with its particularly shallow appliance depth. This is helped by the wall clearance, which is zero centimetres for this flat model. This means that the Saphir can be placed directly against the wall. The result: the compact appliance takes up little space in the room and at the same time
and at the same time offers an impressively wide fire panorama.
Plus point for the environment: the elegant Saphir is not only an absolute eye-catcher; it also ensures efficient and therefore sustainable use of wood as a fuel.

Technical Data

• Manufacturer: SPARTHERM
• Energy efficiency class : A+
• Nominal heat output (closed) kW: 7.5
• Heat output range kW: 5.5 - 9.8
• Efficiency % : >80
• Fuel: Logs
• Combustion system: Closed combustion, dependent on room air
• Glass version: Standard glass, 1-piece
• Door design: sliding door, self closing
• Flue pipe connection diameter mm: 150
• Flue pipe connection top/rear: yes/yes
• Supply air connection: yes 100mm
• Weight kg: 355
• Material: Steel body
• Combustion chamber lining: eboris 1300 ultra fireclay colour ivory (optional black)
• Tests: BImSchV. 2nd stage, DIN EN 13240, Aachen/Munich/Regensburg regulation, Ecodesign 2022,
• Operation possible with type A1 : yes
• Operation possible with type A : --
• Windscreen flushing: yes

Optional accessories:
eboris 1300 ultra black or graphite

Smart fireplace assistance functions
S-Thermatik NEO complete set with black or white display
S-Thermatik NEO basic
S-USI II for wood-burning stoves (factory-fitted)
S-ESAM 3.0

Important note: Before purchasing, please speak to your local district chimney sweep and obtain authorisation from them to operate the desired fireplace.
